BLUETTI AC200MAX Portable Power Station 2200W 2048Wh Expandable

Name: BLUETTI AC200MAX Portable Power Station 2200W 2048Wh Expandable
Brand: Bluetti
SKU: AC200MAX
Price: 1699.00 USD
Availability: InStock

$1,699.00 USD

~~$1,899.00 USD~~ $1,699.00 USD

ON SALE Sold out

Availibility: 11 In Stock

Product variants

Quantity

LOWEST PRICE PROMISE - In the rare scenario that you find this item cheaper elsewhere, please let us know. We will beat the price in most cases!

Click to read our Lowest Price Guarantee details.

FREE SHIPPING. Estimated delivery date is 3-10 days from the order date. We will email you tracking number once your order is shipped.

Click to read our detailed Shipping Policy.

Your mobile power center anywhere, whether at home or on the way - 2200 Watt AC Pure Sine Wave Inverter (4800W Surge) and 2048Wh Capacity

Innovative all-round upgraded expandable power beast - Not just power, get flexibility! With two, expansion ports, this power station is quite expandable. You can boost the total capacity upto 6144Wh by connecting upto two Bluetti B230 expansion battery modules (2048Wh each) or even to a staggering 8192Wh by connecting upto two Bluetti B300 expansion battery modules (3072Wh each)

Incomparable power outlet versatility - With AC200MAX’s 16 outlets, you get to run all your power needs simultaneously without breaking a sweat. For the RV enthusiasts, the AC200 MAX has a specially designed built-in 30A NEMA TT-30 outlet and a 12V 30A super powerful DC outlet.

Gets charged in anyway you prefer with 7 Ways to Recharge (AC/Solar/Car/Generator/Lead Battery/Dual AC/AC+Solar) - The AC200MAX allows up to 900W of solar input and 500W via the adapter, you can even charge it up via your wall outlet and solar panels simultaneously, boost a stunning 1400W total charging rate which can top up your power beast in less than two hours!

Never Run Out of Power - Makes this device a perfect home backup system during an unexpected outage, great solar solution as well as suitable off-grid power source for outdoors, camping, van life, worksite, in the woods, road trip and more with no worry about running out of power. AC 200MAX can power most of your appliances -

Coffee Maker(1150W) - 1.5 Hrs
Electric Grill(1650W) - 1.5 Hrs
Refrigerator 150W - 10 Hrs
Air Conditioner(5000 BTU) - 1-4 Hrs
CPAP(40W) - 30-40 Hrs
Light(10W) - 150+ Hrs
and many more such appliances

Ultra-durable and safe power for everyday needs - Its Lithium Iron Phosphate (LiFePO4) battery offers 3,500+ life cycles to 80% original capacity. Integrated Battery Management System (BMS) monitors everything happening in this device, protecting your device from every potential risk in the day-to-day operations.

Smart Control & Monitor in BLUETTI App

Specifications

BATTERY INFO

Capacity: 2048Wh (51.2V, 40Ah)

Type: LiFePO4 (Lithium Iron Phosphate)

Life Cycles: 3,500+ Cycles to 80% Original Capacity

Shelf-life: Recharge to 80% Every 3-6 Months

Management System: MPPT Controller, BMS, etc

OUTPUT

AC Outlets: 4 x 120V/20A Outlets, 1 x 120V/30A NEMA TT-30, 2200 W In Total

Inverter Type: Pure Sine Wave

Surge Power: 4800 Watt

USB-C Port: 2 x 5V/3A USB-A, 2 x 18W USB-A

12V* DC Outlets: 1 x 12V/30A (RV Outlet), 1 x 12V/10A (Car Outlet), 2 x 12V/10A DC 5521 (5.5mm Outlet)

*All Regulated

Wireless Charging Pad: 2 x 15W Max. (For Each)

INPUT

AC Adapter Input: 500W

Solar Input: 900W Max., VOC 10-145VDC, 15A

Car Input: 12/24V from Cigarette Lighter Port

Max Input: 1,400W, with AC+Solar Input

RECHARGE TIME

AC Adapter (400W): ≈5.5~6 Hours

Solar (900W): ≈3~3.5 Hours (With prime sunshine, ideal orientation and low temperature)

12V/24V Car Outlet (100W/200W): ≈10 or 20 Hours

AC Adapter + Solar (1300W): ≈2.0~2.5 Hours (With prime sunshine, ideal orientation and low temperature)

Dual AC Adapters (800W): ≈3~3.5 Hours (Extra adapter is REQUIRED)

GENERAL

240V Split Phase Bonding: No. Need 240V power source from Bluetti? Explore here.

Scalability: Expandable with upto two Bluetti B230 expansion battery modules or upto two Bluetti B300 expansion battery modules

Pass-through Charging: Yes

Weight: 61.9lbs (28.1kg)

Dimensions (LxWxD): 16.5 x 11 x 15.2in ( 42 x 28 x 38.65cm)

Operating Temperature: -4-104℉ (-20-40℃)

Storage Temperature: 14-113℉ (-10-45℃)

Certifications: UL Standard, CEC, DOE, FCC, CA Prop 65

Click to view AC200MAX user manual

Package Contents

What's in the box?

Warranty

24 Months Warranty by the Manufacturer

Product Gallery

Incomparable Outlet Versatility

With AC200MAX’s 16 outlets, you get to run all your needs simultaneously without breaking a sweat. And especially for the RV enthusiasts the AC200 MAX has a specially designed built-in 30A NEMA TT-30 outlet and a 12V 30A super powerful DC outlet.

Gets Charged In Anyway You Prefer

The AC200MAX allows up to 900W of solar input and 500W via the adapter, you can even charge it up via your wall outlet and solar panels simultaneously, boost a stunning 1400W total charging rate which can top up your power beast in less than two hours! Further more, every BLUETTI battery module has their own input port for AC adapters, you’ll get another 500W of input capability with every module added (Up to two for the AC200MAX).

Frequently Bought Together

1. Bluetti B230 expansion battery - Upto two (of 2048Wh each) can be connected

2. Bluetti B300 expansion battery - Upto two (of 3072Wh each) can be connected

3. BLUETTI PV200 Solar Panel | 200W - For reference only, 4 x BLUETTI PV200: ≈3 hrs. recharge time

4. BLUETTI PV350 Solar Panel | 350W - For reference only, 2 x BLUETTI PV350: ≈3.5 hrs. recharge time

5. BLUETTI PV120 Solar Panel | 120W - For reference only, 5x BLUETTI PV120: ≈4 hrs. recharge time

6. Bluetti DC Charging Enhancer (D050S) - For increasing the PV input rate for BLUETTI AC200Max to 1400W

FAQs

How many BLUETTI B300 or B230 expansion batteries can connect with the AC200MAX?
A: Two B300 for 8,192Wh capacity or Two B230 for 6,144Wh capacity.

Can I connect third-party expansion batteries to AC200MAX?
A: No. AC200MAX ONLY accepts BLUETTI B230 or B300 expansion batteries.

Does AC200MAX support App control?
A: Yes. Once connected via Bluetooth, the BLUETTI App will enable you to control the AC200MAX remotely, like switching the working mode and upgrading the firmware.

Can I use AC200MAX as a UPS?
A: No.

What kind of solar panels should I choose for AC200MAX?
A: PV input requirements for AC200MAX:
Open Circuit Voltage: 10-145V
Input Power: 900W Max.
Includes MC4 connectors.
Highly Recommended:
6x BLUETTI PV120: ≈3.5hrs. For reference only.
4x BLUETTI PV200: ≈3hrs. For reference only.
2x BLUETTI PV350: ≈3.5hrs. For reference only.

Can I connect two units of AC200MAX together for more power (240V Split Phase Bonding)?
A: No.

Is the AC200MAX power station waterproof?
A: No. Also, please do NOT store it in a humid environment for a long time.

Can it charge and discharge at the same time?
A: Yes.

Can I use or charge AC200MAX in sub-zero temperatures?
A: Temperature ranges for AC200MAX are:
Charge: 0-40℃ (32-104℉);
Discharge: -20-40℃ (-4-104℉);
Storage: -20-40℃ (-4-104℉).
Technically, it can power electrical devices under such situations, but please avoid charging it.

How do I know whether my appliance can work well with the AC200MAX?
A:Calculate the total wattage of your devices. AC200MAX should work if the load doesn't exceed its rated 2,200W.

How long can it run my device?
A: Running time = Battery capacity × DoD × η ÷ Device rated power. DoD refers to Depth of Discharge and η is local inverter efficiency.
For AC200MAX, both DoD and η are 90%. If you run a 1,000W microwave oven with it, the running time will be:
2,048Wh × 90% × 90% ÷ 1,000W ≈ 1.65hrs
Note:
1) The formula is NOT suitable for inductive loads with compressors, like refrigerator, air conditioner, etc.
2) The above data is for reference ONLY.

What is the maximum input charging power of the BLUETTI AC200MAX?
A: 1,400W Max. Via 500W wall socket and 900W solar panels simultaneously.

Can it be laid on its side to save space?
A: No. Long-term placement will make the internal structure loose, it is recommended to place the machine upright.

Can I hot-swap expansion batteries to AC200MAX?
A: Yes. You can easily swap battery packs for continuous power use, and the system can hold two batteries at once.

Is it possible to replace the built-in battery?
No. If the battery pack is faulty or even dead, please contact manufacturer BLUETTI's customer service.

What is the difference between the AC200MAX and AC200P?
A: The main differences are:
1. Output power and capacity: 2,000W AC power and 2,048Wh capacity for AC200MAX, while 2,000W and 2,000Wh for AC200P.
2. Max. Input: 1,400W for AC200MAX, while 1,200W for AC200P.
3. Output Port: AC200MAX has a 12V/30A NEMA TT-30 port.
4. App Control: AC200MAX supports BLUETTI App control.
