AIMS Power 6000W Inverter Charger 24Vdc / 240Vac Input & 120Vac / 240Vac Split Phase Pure Sine Output PICOGLF60W24V240VS

Most Popular Feature is its 3x surge capability for upto 20 seconds - This inverter has a direct connect terminal block, which allows a 300 percent surge capacity for up to 20 seconds. When using the terminal block, this inverter peaks at 18000 watts for up to 20 seconds with the power to run many tools and appliances with startup surges, such as refrigerators, freezers, microwaves and blow dryers.

6000 watt 110 Vac / 220Vac Split Phase - This 6000 watt inverter charger produces a pure sine wave, which some appliances require for use. It can run laser jet printers, computers, televisions, CPAP machines and other medical equipment.

Renewable Solar, Off-Grid Home and Business Back-up Power, Mobile and Emergency Back-up Power for applications anywhere that uses 110 / 120 volts OR 220 / 230 / 240 volts of alternating current - This inverter will run powerful tools like most electric chainsaws, portable grinders, shop vacs, and more. Other popular applications for this inverter include powering lights and other appliances in an off-grid cabin, providing electricity for a mobile business or mobile office, and running camping equipment. The inverter accepts 24 volts DC, which makes it great for vehicle upfitting as well as boat and RV applications that use a 24 volt battery system.  The inverter outputs 120V / 240V AC.

Low Frequency Label Inverter - A low frequency label has been given to this inverter because of the lowered level of total harmonic distortion (THD) produced during the DC to AC inversion process. This allows for a cleaner transfer of energy, which increases efficiency, and it also provides a quieter performance.

Automatic Transfer Switch on this unit great for emergency backup power applications - Automatic Transfer Switch keeps the power supply uninterrupted in the event of an outage. With the inverter hooked up to shore power, it will detect the loss of electricity and start pulling energy from a connected battery bank instead to keep the power supply constant. During a big storm that knocks out electricity, a battery-bank and power inverter running a sump pump could be the difference that saves a home from flooding. The power to run a heater could save someone thousands of dollars by keeping plumbing pipes from freezing.

60hz or 50hz selectable dip switch - This inverter can output 50 or 60Hz via the SW4 switch on the product. This means the inverter works internationally and is operable with nearly any electrical system on the planet!

Multi stage smart charger 85 Amp charges gel, Lead, AGM, Lithium batteries. This inverter charger can utilize 240 V grid power to charge the batteries. The current control switch allows you to control the amount of current going into the batteries

8 battery charger settings

10msec typical transfer time

Selectable 25W power save mode (hibernation)

Battery Priority Selector - Though the inverter charger is designed with AC priority as default, switch SW5 on the inverter enables the users to select battery priority mode. This battery priority mode allows you to choose your battery bank over the grid so you can use the renewable power you were harvesting before going back to utility power.

Safety Features like GFCI

Marine Coated and Protected - The marine-coated or conformal-coated boards also make this inverter great for mobile applications, as it protects the product from dust or water vapor that may be present in the air.

Built-in Auto Gen Start Feature - Using a two wire open and close relay, it will automatically start your generator when your battery voltage drops low enough to alarm. The generator can then recharge your batteries while maintaining constant power.

Option to connect Battery temp sensor - You can connect an optional battery temp sensor to this inverter charger to monitor your battery bank and adjust the voltage and current of the charger based on the battery temperature.  This helps preserve and extend battery life. Click here to purchase the Battery temp sensor.

Optional LCD Remote Port - Enables you to connect an optional LCD remote panel to monitor many functions on the inverter from a distance. LCD remote panel is sold separately. Click here to purchase the LCD remote panel.

Specifications

 Inverter Output Specifications:

• Continuous Output Power: 6000 Watts
• Surge Rating: 18000 Watts (20 Seconds)
• Output Waveform: Pure Sine/Same as input (Bypass Mode)
• Nominal Efficiency: >88% (Peak)
• Line Mode Efficiency: >95%
• Output Frequency: 50Hz +/- 0.3Hz / 60Hz +/- 0.3Hz
• Typical Transfer Time: 10ms (Max)
• THD: < 10% DC
• Ambient operating temperature: 14°F to 122°F (-10°C to 50°C)

Input Specifications:

• Nominal Input Voltage: 24V dc
• Low Battery Alarm: 21.0Vdc-22.0Vdc
• Low battery Trip: 20.0Vdc-21.0Vdc
• High Voltage Alarm: 32.0 Vdc
• Low battery Voltage Restart: 26.6Vdc
• Idle Consumption: 76.8 Watts
• Idle Consumption in Power Saver Mode: 29 Watts

Charger Specifications:

• Output voltage: Depends on battery Type
• Charger Rate: 85A

Dimensions:

• Unit Weight: 79 lbs.
• Unit Size L x W x H: 27.88 x 8.5 x 7.0 inches

Click to view User Manual - 6000 Watt Pure Sine Inverter Charger 24Vdc / 240Vac Input & 120/240Vac Split Phase Output

 Package Contents

• The PICOGLF Inverter Charger
• Red and black DC terminal covers
• AC terminal block cover with two Phillips screws
• Two Flange nuts and 4 Phillips screws (installed on the DC terminals)
• PICOGLF Series Owner’s Manual
